OpenWrt Lede Point to Point configuration in bridge mode

OpenWrt lede is latest release of firmware for various OEM hardware. You can get your router supported Lede version from official openwrt hardware table. i have already posted different mode configuration for openwrt such as repeater mode, wisp mode, client bridge mode. In this post I will show how to configure openwrt lede point to point in bridge mode for CCTV and internet connection. Configuration of OpenWrt firmware is little bit different in bridge mode so many people failed to configure it in pure bridge mode.in my personal views it is a best openwrt router for home and office wireless.

Don’t worry after ready this configuration manual you can configure Openwrt firmware version point to point and point multipoint. OpenWrt configuration manual just simple for you once you understand the steps and mode used in openwrt configuration. You can easily configure point to point with both openwrt and non-openrwrt firmware after this post.i have created this tutorial with OpenWrt TP link router but configuration for all openwrt same.



OpenWrt Point to Point Configuration Steps.

Before start configuration I will give steps to follow point to point configuration and avoid any miss configuration.

For point to point two location device need to configure so steps will be same for both side location device as given below.



  1. OpenWrt Device Login First time
  2. LAN & DHCP configuration
  3. OpenWrt Wireless Mode Configuration

See Also – OpenWrt(LUCI) Repeater (Client+AP) Configuration

OpenWrt Client Router (WISP) Configuration (with Picture)

Point to Point Location A device Configuration

Ready your both OpenWrt device to proceed configuration.

Login Device.

OpenWrt Default IP address is 192.168.1.1 and username –root, password blank on default.

Connect device and open 192.168.1.1 to browser.

openwrt TP Link point to point



2:- Openwrt Lede LAN & DHCP configuration

Point to point configuration use to connect 2 different site wirelessly. So we also required 2 wireless radio to connect both side. OpenWrt lede comes with default ip address so it’s necessary to change the default IP address to avoid network conflict issue.

To chang IP Address Go to Network –Interfaces



Click Edit on LAN and change ip address and disable DHCP server.

 openwrt remote access enable

To Change IP and DHCP configuration click here

OpenWrt firmware upgradation with SSH command (with Piture)

3:-OpenWrt Lede Access Point WDS mode Configuration for PTP.

Now first site device will be configure as Access point WDS mode. OpenWrt point to point work as AP and client device for both side. So see AP WDS configuration for site A.

To configure Wireless

Go to Network- Wireless

openwrt ptp and ptm

Click Edit button in wireless interface.

openwrt alternatives



Device Configuration

  • Wireless network is disabled – Click Enable button first ( button should show red button )
  • Mode- N , Channel – choose -11 or any other , Width- 20 (use 40 if non-interface area)

openwrt default password

Interface Configuration

  • ESSID- user your Network SSID name here (use unique name which can find easily in multiple network name)
  • Mode- Access Point WDS ( choose Access WDS mode)
  • Network –choose LAN
  • Save & Apply to save settings

Beginners' Guide to OpenWrt



OpenWrt Lede Wireless Security configuration.

  • Click the Wireless security tab from interface configuration
  • Encryption – WPA2PSK recommended
  • Key – type your wireless password ( this password will use to connect client device)

 openwrt point to point birdge mode with ubnt AP

After configuration Access point now second location device configure as client wds mode.



Location B Configuration–

OpenWrt Lede Client WDS configuration for Remote Location

OpenWrt Client Mode

Now Go to Network- Wireless

openwrt ptp and ptm



Click Scan button to find your Access Point SSID.

openwrt luci ping not with mikrotik ap



You will find many wireless network name while scanning outdoor. Find you network ssid and click Join Network

openwrt connected but no ping from AP



In next steps you need to type Wireless password you configure in Access point mode.

  • WPA passphrase- type password here
  • Name of the new network- you can type any name here to recognize your Ethernet,
  • Choose LAN in this steps ( LAN will be selected for bridge mode )
  • Submit setting after all settings.

openwrt can ping from router but not outside



This steps is very important to configure openwrt in bridge mode.

  • Mode should be Client WDS for bridge
  • Lan select
  • Click save and apply for saved settings.

openwrt firmware upgrade lede

After settings saved your device will connected to Access point device and you can check signal status on Wireless option.



In status you can see remote device Mac address signal with noise.

You can see connected RX rate and TX rate here.

openwrt not show rx tx

This manual also support all the openWrt version like OpenWrt Luci,  openwrt chaos calmer, Attitude adjestment and OpenWrt LEde.

OpenWrt Lede Point to Multi Point Configuration

to configuration openwrt point to multi point just repeate the steps Openwrt client wds configuration for 3 (third) openwrt device for multi point. you can connect multiple openwrt client device to Access point device.
